Tube type module also know as circular tube membrane module,is a tubular membrane separation unit equipment obtained by attaching a semi permeable membrane on the inner or outer side of a circular tube support
Parameter
| Insulation for Header | ||
| Model | Qty | |
| Liquid | Vapor | |
| JHBL054 | 1 | 1 |
| JHBL104 | 1 | 1 |
Header Connection Diameters(in,ID)
| Model | Header Tyрe |
Port ldentifier | ||||||
| 1 | 2 | 3 | 4 | 5 | 6 | 7 | ||
| JHBLO54 | Liquid | - | 3/8 | 1/2 | 3/8 | 1/4 | 3/8 | 1/4 |
| Vapor | - | 5/8 | 1/2 | 5/8 | 1/2 | 5/8 | 1/2 | |
| JHBL104 | Liquid | - | 3/8 | 1/2 | 5/8 | 3/4 | 1/2 | 5/8 |
| Vapor | 7/8 | 1 | 1-1/8 | 3/4 | 5/8 | 5/8 | 1/2 | |
Header Dimensions'(in)
| Model | Header Type | A | B | C | D | E | F | G |
| JHBL054 | Liquid | 5-29/32 | 4-23/32 | 4-23/32 | 7 | 9-15/32 | 11-27/32 | 14-5/32 |
| Vapor | 5-29/32 | 4-23/32 | 4-23/32 | 7 | 9-15/32 | 11-27/32 | 14-5/32 | |
| JHBL104 | Liquid | 5-29/32 | 4-23/32 | 4-23/32 | 7 | 9-15/32 | 11-27/32 | 14-5/32 |
| Vapor | 5-29/32 | 4-23/32 | 6-5/16 | 8-11/16 | 11-1/16 | 13-7/16 | 15-23/32 |
